Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS

Looking for a Full Automatic Four Edge Plywood Trimming Cutting Saw Machine for your Plywood/Furniture Factory? We have the CE/SGS certified products you need. Buy direct from the factory!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Automatic
Automatic
Certification
CE, ISO, Plywood Machine
Precision
High Precision
Voltage
380V
Overall Size
8000*5000*1200mm
Weight
5000kg
Application
Wood Panel and Other Manufacturing Plant
Power
39kw
Model
Gtpm48
Long Saw Cutting Size
1830-2440mm
Lateral Saw Cutting Size
800-1220mm
Working Speed
10-30m/Min
Saw Blade Dimension
Diameter305mm,Inner Diameter25.4mm
Capacity
8-12PCS/Min
Working Style
Infrared Ray Guidance
Working Method
Full Automatic
Transport Package
Container
Specification
4*8
Trademark
GTCO
Origin
China
HS Code
84289090
Production Capacity
20 Set/ Month

Product Description




Product Description
Plywood edge trimming saw / panel saw/ edge cutting saw is the necesary and one of the most imortant machine during the plywood production process ,it cutting the rough said to the regular side as client request.
Automatic edge trimming saw replance the old manual operation work way ,totally Automatic , save labor ,and btter work performance .

Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS

Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS





Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
Strong structure
The whole machine is made from suare iron 150x100mm . And double  base bridge . total weight up to 7 tons .
its strong enough ,and promise it wont out of shape during long work life



MODEL SIZE


Model  36 48
plywood size  3x6ft  4x8ft
plywood thickness  3-70mm 3-70mm
speed  300pcs/h 300pcs/h
power  42kw 48kw
Servo motor  2kwx2 2kwx2
saw head power  9kw 9kw
machine size  5.4mx5.4mx1.7m 5.8mx5.8mx1.7m
weight    6 tons  6 tons






Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS




CONTAINER LOADING




Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS







     RELATIVE  MACHINERY

Full Automatic Four Edge Plywood Trimming Cutting Saw Machine Used for Plywood /Furniture Factory with CE/SGS
