Basic Info.
Model NO.
Heightening engraving machine
Working Area
1300*2500*700mm
Power
3.0kw,5.5kw
Operation Mode
Hybrid Servo Motor/Servo Motor/Stepping Motor
Cooling Method
Air Cooling/Water Coolng
Control System
Nc Studio/DSP/Match3
Transport Package
Plywood Packaging
Specification
2300*3400*1600mm
Trademark
Songli
Origin
China
HS Code
8465990000
Production Capacity
280 Sets/Month
Product Description
1325 heightened CNC engraving machine
| Product mode | 1325 woodworking engraving machine |
| Table Size | 1300mm*2500mm |
| Z-axis lifting size | 1200mm |
| Spindle type | ordinary constant power |
| Spindle cooling mode | air cooling and water cooling |
| Spindle power (optional) | 2.2 kW, 3.2 kW, 5.5 kW, 6.5 kW |
| Driving system | XY gantry double drive |
| Z-Shaft Drive System | High Precision Ball Screw |
| Maximum speed | 20 m/min |
| Manufacturer | Shandong Songli Machinery Co., Ltd. |
| Location accuracy | +-0.35mm/1000mm |
| Repeated positioning accuracy | +-0.02mm/1000mm |
| Running instructions | G code F/S command compatible |
| Power requirements | 220V/380V |
| Machine weight | 1000kg |
| Outline size | 3000mm long, 2000mm wide, 2600mm high |
| Operating system | Ncstudio |
| Square track frame (optional) | 20, 24, 25 square track swivel |
| Operating Motor | stepping, hybrid servo, AC pure servo |
| Body color | black, red, blue and white |
| Oil filling method | semi-automatic oil filling system |
Product Application
1325 CNC wood engraving machine can be used in the furniture industry, furniture industry, carpenter decoration industry, instrument industry, woodworking industry, furniture industry, the machine is suitable for large area of plate plane carving, wood carving, wood furniture art murals carving, wood carving, density board wenqi door, door window carving carving.Is home decoration industry replacement products.
Wooden industrial products: such as sewing table, electrical cabinet panel, sports equipment and so on.
Mold industry: can carve all kinds of mold, wood mold, propeller, automobile foam mold.
Musical instrument industry: it can carve three-dimensional curved surface of musical instrument and cut it.
Such as advertising, craft gifts industry, art model industry, wood processing industry, mold industry and so on.The materials that can be processed include acrylic, double color board, PVC, ABS board, stone, imitation stone, metal, aluminum-plastic board and other materials.
Advertising industry: carving, cutting all kinds of signs, signs, marble, copper, font, all kinds of signs, trademarks and other metal materials.
Arts and crafts industry: arts and crafts, souvenirs engraved all kinds of text, graphics, iron works of art carving, dial.
Mold processing: building model, physical model, hot stamping mold, motor, high frequency mold, trace injection mold, shoe mold, badge, embossing mold, cookie, chocolate, candy mold.
Wooden industrial products: such as sewing table, electrical cabinet panel, sports equipment and so on.
Mold industry: can carve all kinds of mold, wood mold, propeller, automobile foam mold.
Musical instrument industry: it can carve three-dimensional curved surface of musical instrument and cut it.
Such as advertising, craft gifts industry, art model industry, wood processing industry, mold industry and so on.The materials that can be processed include acrylic, double color board, PVC, ABS board, stone, imitation stone, metal, aluminum-plastic board and other materials.
Advertising industry: carving, cutting all kinds of signs, signs, marble, copper, font, all kinds of signs, trademarks and other metal materials.
Arts and crafts industry: arts and crafts, souvenirs engraved all kinds of text, graphics, iron works of art carving, dial.
Mold processing: building model, physical model, hot stamping mold, motor, high frequency mold, trace injection mold, shoe mold, badge, embossing mold, cookie, chocolate, candy mold.
